2023 CANYON GRIZL CF SLX 8 FORCE AXS TRAIL ROAD BIKE
A shock-absorbing carbon seatpost
Combining the shock-absorbing properties of carbon with our revolutionary Leaf Spring design, get outstanding comfort for the long haul with this S15 seatpost. Enjoy a stable, supportive feel on the flats with up to 20 mm of flex to soak up hits and vibrations – all without the need for any suspension components.
50 mm tyre clearance
We developed the frame to provide 50 mm of tyre clearance with 700C wheels (45 mm with fenders). For this we had to push the boundaries in many areas, like with the dropped drive-side chainstay. It is extremely thin while still providing structural support and internal cable routing.
Top tube mount
The easiest way to access your most frequently used items. Ideal for storing your phone, gels, and small tools. The bolt-on design and waterproof construction keeps everything safe, secure, and dry.
Lightweight, robust 950 g frame
Burly and fast. The Grizl CF SLX uses advanced carbon materials and layup techniques for a complete frame weight of just 950 g – outshining many classic road bike frames on the market.
SPECIFICATION :
| Frame | Canyon Grizl CF SLX Axle dimension: 12x142 mm Tyre Clearance: 50 mm Material: Carbon (CF) |
|---|---|
| Suspension Fork | Rock Shox Rudy Ultimate Axle dimension: 12x100 mm Stanchion Diameter: 30 mm Travel: 30 mm Fork steer tube diameter: 1 1/4" |
| Battery | SRAM Powerpack |
| Rear Derailleur | SRAM Force XPLR eTap AXS, 12-speed |
| Cassette | SRAM Force XPLR XG-1271, 12-speed, 10-44 Number of sprockets: 12 |
| Crank | SRAM Force AXS Powermeter Number of chainrings: 1 |
| Bottom bracket | SRAM Pressfit RED DUB Bottom bracket standard: PF 86,5 |
| Chain | SRAM Force D1 12s |
| Shift-/ Brake Lever | SRAM Force eTap AXS, 1-speed |
| Shift-/ Brake Lever | SRAM Force eTap, 12speed |
| Brake Rotor | SRAM Centerline Rounded Size: 160 mm |
| Wheel | Reynolds ATR Rotor mount: Center Lock Wheelsize: 28" |
| Wheel | Reynolds ATR XDR Rotor mount: Center Lock Wheelsize: 28" |
| Tyre | Schwalbe G-One Bite 45mm Width: 45mm |
| Thru Axle | Canyon Thru Axle Axle dimension: 12x142 mm |
| Stem | Canyon ST0035 Fork steer tube diameter: 1 1/4" Clamping diameter: 31,8 mm |
| Handlebar | Canyon HB0063 Clamping diameter: 31,8 mm Width: 440 mm |
| Handlebar Tape | Canyon Ergospeed Gel Color: black |
| Saddle | Fizik Argo Terra X3 Gender: Male |
| Seatpost | Canyon S15 VCLS 2.0 CF Material: Carbon Setback: 13 mm / 25 mm Technology: VCLS 2.0 | Fliphead Weight: 220 g |
| Light | Reflector Set |
| Pedals | None included |
| Manuals and Accessories | Canyon Small Box |
| Manuals and Accessories | Canyon Shock Pump |
| Manuals and Accessories | Canyon starter box |
| Manuals and Accessories | Canyon Quick Start Guide |
